Home Product Magnetic Equipment Magnetic Drum
Magnetic Drum
- 【Introduction】:
- 【 Capacity 】:
- 【Improvement】:
【Advantages】
Large feeding particle size (450～0mm), no classification before feeding;
High strength and high reliability of the mechanical structure guarantee the normal work of the magnetic drum in a variety of harsh environment.
【Product Structure】
The materials are uniformly fed to the belt. When materials go through the permanent magnetic drum, the non-magnetic and low-magnetic particles will leave the belt surface because of the centrifugal force and gravitation. Meanwhile, strong-magnetic particles are absorbed to the belt by magnetic force and then fall into the magnetic trough when the belt leaving the magnetic pulley.
【Technical Parameters】
| Model & Spec. | Diameter of Cylinder (mm) | Length of Cylinder (mm) | Width of Belt (mm) | Surface Magnetic Density (mt) | Capacity (t/h) |
Feed Size (mm) | Total Weight (t) |
| CTGG-0812 | 800 | 1200 | 1000 | 300~500 | ≤100 | ≤200 | 2.1 |
| CTGG-0814 | 800 | 1400 | 1200 | 300~500 | ≤120 | ≤200 | 2.6 |
| CTGG-0816 | 800 | 1600 | 1400 | 300~500 | ≤150 | ≤200 | 3.2 |
| CTGG-0818 | 800 | 1800 | 1600 | 300~500 | ≤180 | ≤200 | 3.9 |
| CTGG-1018 | 1000 | 1800 | 1600 | 300~500 | ≤270 | ≤250 | 4.4 |
| CTGG-1218 | 1200 | 1800 | 1600 | 300~500 | ≤350 | ≤300 | 5.0 |
【Successful case】
In an iron concentrate plant, the lean ore processed magnetic separation after coarse crushing and medium crushing, in order to restore grade, save energy and improve production, the customer chose magnetic drum, reducing the load of next procedure. Arrangement of two stages magnetic separation, the intensity of magnetic field is large, the magnetic separation effect is very obvious, and production efficiency is improved; at the same time, magnetic drum can also be used to process tailings, which is beneficial to recycle equipment, save the cost and improve grade.
